Automated Line

Maximize your production with full automation

Designed for dental laboratories, the Automated Lines optimize your workflow by automating key production steps with a ceramic 3D printer. Increase efficiency, minimize manual labor, and ensure continuous, high-quality uninterrupted output.

Download Data sheet Get a quote

Prodways Machines_modular-dental_3d-printers_automated-workflow

Key Features & Benefits

Uninterrupted production

Live status updates for complete control.

Reduce human intervention

Free your technicians for high-value tasks

Precision & speed fully automated

Ensures repeatable, high- quality production every cycle.

Faster ROI

Designed for fast and scalable production in dental labs

Get a quote

Automated Line Specifications

Number of DLP® Heads

1 or 2 (up to +40% faster)

Technology

UV-LED DLP®: 385nm or 405 nm wavelength

Applications

All Dental Application : Aligner Models, Dentures*, Crown & Bridge models, Trays, Orthodontics & Implantology models
*only on DENTAL PRO 100 & 200

Materials Qualified

Absolute Aligner, Provivic Denture Base, PLASTCure Modele 300/310/320 (non exhaustive list)

Light Power **

90 mW / cm²

Max. Build envelope size (LxWxH)

300 x 445 x 2350 mm | Customizable configuration possible based on needs

Native pixel size (X, Y)

42 μm (0.0016 inches)

Layer thickness*

50 – 175 μm (0.001 to 0.006 inches)

Platform type

Granite, perforated or metal platform

Printer size (LxWxH)

1600 x 1100 x 1780 mm | 62.9 x 43.3 x 70.1 inches

Weight

710 Kg | 1575 lbs.

Power requirements

210 – 240 VAC, 8-12A, 50/60 Hz

Download Data Sheet

*Please note that this data is contingent upon factors including but not limited to part geometry, build style, and material. Variations in these elements may affect outcomes.

**All technical characteristics, specifications, and data provided in this document are non-binding and subject to individual use cases and environmental conditions. Performance and results may vary based on these factors.
